The expandable container house is versatile in its applications, serving various purposes such as residential housing, office spaces, dormitories, retail shops, bars, emergency shelters, disaster relief rooms, and more. Its adaptability makes it suitable for a wide range of needs, from providing comfortable living spaces to serving as functional commercial or emergency facilities.
Features and Specifications
Model | External Dimensions(mm): | Pack size (cm) L*W*H | Weight (kg) | Load num |
10FT | W6448*L2940*H2510(side:2270) | 295*220*248 | 1500 | 4 sets/40’HQ |
20FT | W6210*L5850*H2510(side:2270) | 590*220*248 | 2500 | 2 sets/40’HQ |
20FT mini | W4710*L5850*H2510(side:2270) | 590*70*248 | 2000 | 6 sets/ 40’HQ |
40FT | W6130*L11700*H2510(Side:2180) | 1180*220*248 | 5000 | 1 sets/ 40’HQ |
Detailed Specifications for Modular Container Housing | |
Item Name | 10ft 20ft 20ft mini 40ft Expandable Container House Stackable Foldable Prefab Modular Living Homes |
Main Material | Galvanized Steel Structure with Sandwich Panel Wall and Doors, Windows,etc. |
Weight | 1800-5500kg |
Service Life | More than 10 years |
Steel | 3mm Hot Galvanized Steel Structure with 4 corners casts |
Wall | 50mm/75mm/100mm EPS/Rock Wool Fireproof Sandwich Panel |
Roof | 50mm /75mm Glass Wool Fireproof Sandwich Panel |
Entrance door | Black broken bridge aluminum double doors, tempered double-layer glass 5+12+5，size：W1990*H2175mm |
Bedroom door | White aluminum wooden door with door pocket, dimensions: W840*H2035mm |
Window | Double Glazed PVC/Aluminum Window with Window Screenand Guard Net Made of PVC/aluminum frame W1120*H1100mm, glazed with double glass in a thickness of 5/8/5mm. |
Floor | MGO Board/Optional Floor |
Connection kits | PVC Connection Kits for ceiling, floor and walls. |
Electricity | 3C/CE/CL/SAA Standard with Distribution Box, Lights, Switch, Sockets,etc. |
Roof Frame | 3.0-4.0mm Profile Steel |
Floor Frame | 3.0-4.0mm Profile Square Tube |
Corner Post | 3.0-4.0mm Profile Square Tube |
Option Accessories | Furniture, Sanitary ware, Kitchen, A/C electrical appliance for accomodation, office, Dormitory |
Advantage | (1) Fast installation: 2 hours/set, saving labor cost (2) Anti-rust: all material use hot galvanized steel (3) Waterproof: without wood ceiling (4) Fireproof: fire rating A grade (5) Simple foundation: just need 12pcs concrete block foundation (6) Wind-resistant (11 level) and anti-seismic (9 grade) |
